SIM362 5″ HMI

SIMx62 Technical Product Brief (TPB)

SIM362 is a future product; Contact Serious for details.

SIM362 will be an Extended Lifetime Product and recommended for new designs

The SIM362 features a premium, high resolution 5″ 800×480 color LCD powered by the Renesas RZ/G1E MPU with 1GHz dual Cortex A7 cores. Utilizing our proprietary SHIPEngine firmware, the SIM362 delivers a large array of options for front panel applications with industrial, commercial, and medical applications in a small package.

Featuring built-in RS485/UART and high-speed USB connectivity, SIMx62 family members are easily integrated into existing system designs. The 30-pin expansion connector provides further expandability to custom daughter-cards or off-the-shelf Serious Communications/Control Modules for extensive connectivity (including WiFi, Bluetooth, Ethernent, RSxxx, CAN, and more) as well as powerful system control.



Explore these options compared to the SIM362:

  • SIM152 for similar capabilities in a more cost-effective, very compact 3.5″ form factor
  • SIM252 for similar capabilities in a more cost-effective, compact 4.3″ form factor
  • SIM352 for a more cost-effective 5″ solution without video playback
  • SIM552 for a cost-effective, larger 7″ form factor without video playback
  • SIM562 for similar performance in 7″, including video playback
  • SIM862 for similar performance in big, bold, 10.1″ LCD experience, including video playback

FEATURES & VARIANTS

Processor and Memory
  • Renesas RZ/G1E Dual 1GHz ARM Cortex A7 MCU
  • 256MB DDR1333 DDR3 DRAM
  • 4GB e.MMC storage for program, non-volatile data, and files system storage
  • μSDCard socket for (user supplied) memory cards for file system expansion and firmware/GUI updates
Integrated graphics/touch and audio I/O:
  • Integrated LCD with optional touch controller and ambient light sensor for high brightness LCD options
  • Integrated audio codec/amplifier with line/headphone, headphone detect, and 3W speaker outputs
  • External codec/amplifier support
Numerous communications ports
  • USB 2.0 high speed 480mbps host port A connector
  • USB 2.0 high speed 480mbps device port Micro B connector
  • RS422/485 port with selectable duplex and termination
  • 3V UART with transmit control (separate from RS485 port)
Simple in-chassis connectivity
  • Direct Dock to Generation 5 Serious Comms/Control Modules (SCMs, e.g. SCM318)
  • 16-pin JST ZPD series wire-to-board connector (RS485/UART, Power, RESET#)
  • 6-pin industrial 3.5mm pluggable connector (RS485, Power)
  • 4-pin audio headphone/line out connector and 3-pin speaker connector
Wide Operating Range
  • 8-35VDC wide range power supply input
  • -40 to +85C operating temperature range components (further limited by LCD option)256
FEATURE/VARIANTA01A05
LCD
Size (inches)5″ (SIM362), 7″ (SIM562), 10.1″ (SIM862)
Touch OptionsCapacitive, Resistive, None
Operating Range
Vin10.8-35.0 VDC
Operating Temp-40 to +85C (further limited by LCD)
MCU & Storage
FamilyRenesas RZ/G1E
Core1GHz Dual Cortex A7
e.MMC Flash (MB)4096
RAM TypeDDR3
RAM Size (MB)256
µSDCard SocketYN
Peripherals
Battery Backed RTCCY
Ambient Light SensorSee LCD
Audio OutputI2S
Line Out
3W Amp		I2S
Connectivity
Host Port/Speed (Mbps)480
USB Host A ConnectorYN
Device Port/Speed (Mbps)480480
USB Device µB ConnectorYY
UART11
RS422/485 Transceiver10
2×15 Board-To-Board 1,27mm”YY
16-pin JST Wire HarnessYN
6-pin Industrial 3,5mmYN

LCD OPTIONS

See LCD Options for definitions and codes. Additional options may be available; contact your local Serious representative for details.

Capacitive Touch Options

In development, Contact Serious

Resistive Touch Options

In development, Contact Serious

Non-Touch Options

In development, Contact Serious

DEVELOPMENT TOOLS AND SOFTWARE

SHIPTide GUI Development IDE

  • Pixel accurate page layout
  • Built-in media support: jpg, png, bmp, tif, ttf, wav, and more
  • Windows 10 based

SHIPEngine Runtime GUI Engine

  • Licensed with every SIM
  • Runs GUIs generated by SHIPTide
  • Handles graphics, touch, communications, events, and more

SIMx52 and SIMx62 (“Generation 5”) HMI modules are supported by SHIP v5.2.

Learn More about the Serious Human Interface™ Platform (SHIP)





DEVELOPMENT KITS

The SIMx52 and SIMx62 Development Kits

SIMx52 and SIMx62 HMI modules are supported by SIM Dev Kit Accessory (SIMDKA) packages. Just purchase separately the individual HMI module of your choice, and add the appropriate DKA as a build-your-own dev kit.

SIMx52/x52 Dev Kit Accessories
